GE-SFP-LX20-SM1550-BIDI Optical Transceiver, 1.25G 1550nm 20km
Stok 25
Highlight Features:• 1000BASE-LX BIDI SFP Transceiver (Single Mode, 1550nm).• Supports up to 20km transmission over single-fiber.• High-reliability laser with industrial protection.• Simplifies fiber cabling by using only one strand.
Ruijie GE-SFP-LX20-BIDI: Koneksi Fiber 20KM Melalui Satu Core
Jembatani jarak hingga 20 kilometer dengan efisiensi kabel yang tak tertandingi menggunakan GE-SFP-LX20-SM1550-BIDI. Sebagai pasangan modul BIDI, transceiver ini memastikan komunikasi Gigabit jarak jauh tetap stabil hanya dengan satu helai kabel Single-Mode.
Fitur Unggulan:
- Jangkauan Jauh 20KM: Pilihan tepat untuk menghubungkan kantor pusat ke cabang atau area publik yang luas secara ekonomis.
- Teknologi BIDI Cerdas: Mengurangi kebutuhan infrastruktur kabel fisik tanpa mengorbankan bandwidth Gigabit.
- Keandalan Enterprise: Memastikan uptime jaringan yang tinggi dengan teknologi laser presisi untuk meminimalkan loss sinyal.
| brands |
|---|
Technical Specifications
| Module Type | SFP BiDi Transceiver |
| Wavelength | TX 1550nm / RX 1310nm |
| Media Type | Single Mode Fiber (SMF) |
| Max Distance | 20 km |
| Data Rate | 1.25 Gbps |
| Connector | Simplex LC |
| TX Power | -9 ~ -3 dBm |
| RX Sensitivity | < -22 dBm |
| Saturation | -3 dBm |
| Operating Temp | 0°C to 70°C |
| Hot Swappable | Yes |
| DDM/DOM | Supported |
| Supply Voltage | 3.3V |
| Power Consumption | < 1W |
| Laser Type | FP/DFB Laser |
| Receiver Type | PIN-TIA |
| Compliance | IEEE 802.3z, SFP MSA |
| Fiber Diameter | 9/125μm |
| Extinction Ratio | > 9 dB |
| Storage Temp | -40°C to 85°C |
| Weight | 0.02 kg |
| Safety | Class 1 Laser Safety |
| EMI/EMC | FCC, CE |
| RoHS | Compliant |
| Application | FTTH, Gigabit Ethernet |
| MTBF | > 1,000,000 hours |
| Link Budget | 13 dB |
| Reliability | Telcordia GR-468 |
| Housing | Full Metal Enclosure |
| Warranty | 3 Years |
