GE-SFP-SX-MM850 Optical Transceiver, 1.25G 850nm 550m
Stok 25
Highlight Features:• 1000BASE-SX SFP Transceiver (Multi-Mode, 850nm).• Supports up to 550m over OM2/OM3 multi-mode fiber.• Best-in-class performance for short-range fiber links.• Low latency and high-speed data transmission.
Ruijie MINI-GBIC-SX: Transceiver Fiber Multi-Mode untuk Jarak Dekat
Maksimalkan kecepatan jaringan di dalam gedung dengan modul MINI-GBIC-SX. Menggunakan serat optik Multi-Mode (850nm), transceiver ini adalah solusi paling efisien dan ekonomis untuk konektivitas Gigabit antar rak server atau antar lantai hingga jarak 550 meter.
Kenapa Memilih Modul Ini?
- Pilihan Paling Ekonomis: Solusi terbaik untuk koneksi fiber jarak dekat di dalam satu bangunan.
- Kecepatan Gigabit Murni: Menghilangkan interferensi elektromagnetik yang sering terjadi pada kabel tembaga standar.
- Efisiensi Daya: Konsumsi listrik yang sangat rendah membantu menjaga efisiensi energi di ruang server Anda.
| brands |
|---|
Technical Specifications
| Module Type | 1000BASE-SX SFP |
| Wavelength | 850nm |
| Media Type | Multi-Mode Fiber (MMF) |
| Max Distance | 550 meters (OM2) |
| Data Rate | 1.25 Gbps |
| Connector | Duplex LC |
| TX Power | -9 ~ -3 dBm |
| RX Sensitivity | < -18 dBm |
| Saturation | 0 dBm |
| Laser Type | VCSEL Laser |
| Supply Voltage | 3.3V |
| Operating Temp | 0°C to 70°C |
| Storage Temp | -40°C to 85°C |
| DDM Support | Yes |
| Hot Swappable | Yes |
| Power Consumption | < 0.6W |
| Fiber Diameter | 50/125μm or 62.5/125μm |
| Link Budget | 9 dB |
| Safety | Class 1 Laser Safety |
| Compliance | IEEE 802.3z, SFP MSA |
| RoHS | Compliant |
| MTBF | > 1,000,000 hours |
| EMI/EMC | FCC, CE |
| Housing | Zinc Alloy Shell |
| Weight | 0.02 kg |
| Interface | Plug-in SFP |
| Forwarding Mode | Full Duplex |
| Durability | > 500 cycles |
| Humidity | 5% to 95% RH |
| Warranty | 3 Years |
