RG-CS85-24SFP-8GT8XS-D L3 Managed Switch, 24 x SFP, 8 x Gigabit Combo, 8 x 10G SFP+
Stok 25
Highlight Features:• 24 x SFP fiber ports with 8 x Combo RJ45 ports.• 8 x 10G SFP+ uplinks for massive bandwidth.• Redundant DC/AC power supply options.• Advanced network virtualization (VSU) support.
Ruijie RG-CS85-24SFP: Pusat Agregasi Fiber untuk Jaringan Kampus Modern
Maksimalkan jangkauan jaringan Anda dengan koneksi fiber optik. Dengan 24 port SFP, switch ini adalah pilihan sempurna untuk menjadi pusat agregasi yang menghubungkan berbagai switch akses di lokasi berjauhan melalui kabel fiber.
Fitur Kunci:
- Konektivitas Fiber Dominan: 24 port SFP memberikan fleksibilitas koneksi jarak jauh tanpa gangguan interferensi listrik.
- Dual Media Uplink: Kombinasi port Gigabit Tembaga dan 10G SFP+ memberikan pilihan fleksibel untuk koneksi ke core network.
- Optimasi Trafik Video: Sangat handal dalam menangani lalu lintas data CCTV atau video streaming tanpa buffering.
- Manajemen Cloud yang Powerfull: Kontrol seluruh jaringan fiber Anda dalam satu tampilan dashboard yang intuitif dan mudah dipahami.
| brands |
|---|
Technical Specifications
| Type | L3 Aggregation Fiber Switch |
| Fixed Ports | 24 x 100/1000Base-X SFP Slots |
| Combo Ports | 8 x 10/100/1000Base-T Ports (Combo) |
| Uplink Ports | 8 x 10G SFP+ Slots |
| Switching Capacity | 208 Gbps |
| Forwarding Rate | 156 Mpps |
| MAC Address | 32K Entries |
| L3 Routing | Full L3 Stack (OSPF, BGP, ISIS) |
| Stacking | VSU 2.0 Support |
| Management | Web, CLI, SNMP, Ruijie Cloud |
| Reliability | Dual Hot-swap Power Supply |
| Power Supply | AC 100-240V / DC -48V Modules |
| Power Consumption | < 65W |
| Dimensions | 440 x 330 x 44 mm (1U) |
| Weight | 5.5 kg |
| Cooling | Hot-swap Fan Tray (N+1) |
| Operating Temp | 0°C to 50°C |
| Security | CPP, NFPP, DHCP Snooping |
| VLAN | 4K VLANs, Super VLAN, Private VLAN |
| ARP Table | 16K Entries |
| IPv6 | Dual Stack Ready |
| Multicast | IGMP v1/v2/v3, MLD Snooping |
| QoS | Strict Priority, WRR, Traffic Shaping |
| Mirroring | Many-to-One SPAN |
| Jumbo Frame | 9216 bytes |
| Surge Protection | 10KV |
| Housing | Full Metal Industrial Design |
| Certification | CE, FCC, RoHS |
| MTBF | > 180,000 hours |
| Warranty | 3 Years |
