RG-CS85-48GT4XS-HPD L3 Managed Switch, 48 x 10/100/1000BASE-T Ports (High PoE), 4 x 10G SFP+
Stok 25
Highlight Features:• 48 x 10/100/1000BASE-T PoE+ ports with high power budget.• 4 x 10G SFP+ uplink ports for non-blocking data transfer.• Supports IEEE 802.3bt (90W) on specific ports for high-power devices.• Intelligent PoE management and scheduling via Ruijie Cloud.
Ruijie RG-CS85-48GT4XS-HPD: High-Power PoE untuk Ekosistem Smart Building
Optimalkan instalasi perangkat IP Anda dengan RG-CS85-48GT4XS-HPD. Switch ini tidak hanya menawarkan kapasitas port yang luas, tetapi juga dukungan High-Power PoE yang sanggup menyuplai daya ke perangkat berat seperti CCTV PTZ, layar digital signage, dan AP Wi-Fi 6 berkinerja tinggi hanya melalui satu kabel LAN.
Fitur Unggulan:
- Output PoE yang Tangguh: Mendukung standar PoE daya tinggi untuk menghidupkan perangkat canggih tanpa perlu adaptor listrik tambahan di setiap lokasi.
- 48 Port Gigabit & 4 Port 10G Uplink: Kombinasi sempurna untuk distribusi daya besar dan transmisi data berkecepatan tinggi secara bersamaan.
- Proteksi Listrik Industrial: Dilengkapi dengan perlindungan lonjakan arus (surge protection) untuk menjaga perangkat Anda tetap aman dari gangguan kelistrikan.
- Efisiensi Manajemen Daya: Fitur cerdas yang secara otomatis mengatur distribusi daya berdasarkan kebutuhan riil tiap perangkat.
| brands |
|---|
Technical Specifications
| Type | L3 Managed High-Power PoE Switch |
| Fixed Ports | 48 x 10/100/1000Base-T (PoE+) |
| Uplink Ports | 4 x 10G SFP+ Slots |
| PoE Standard | IEEE 802.3af/at/bt (Partial) |
| PoE Budget | 740W (Expandable to 1440W) |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 132 Mpps |
| PoE Features | Per-port PoE priority, Perpetual PoE |
| L3 Protocols | OSPF, BGP, ISIS, Static, RIP |
| Virtualization | VSU 2.0 Support |
| Power Supply | Dual Hot-swap Redundant Slots |
| Power Consumption | < 1600W (Full Load) |
| Dimensions | 440 x 420 x 44 mm (1U) |
| Weight | 7.5 kg |
| Operating Temp | 0°C to 50°C |
| Cooling | Intelligent N+1 Redundant Fans |
| MAC Address | 32K Entries |
| ARP Table | 16K Entries |
| VLAN | 4K VLAN IDs, QinQ |
| Security | CPP, NFPP, Port Security, ACL |
| IPv6 | Full Dual Stack Support |
| QoS | 8 Queues, SP, WRR, WRED |
| Multicast | IGMP v1/v2/v3, PIM-SM |
| Reliability | BFD, VRRP, REUP |
| Jumbo Frame | 9216 bytes |
| Surge Protection | 10KV (High Reliability) |
| Management | CLI, Web, Cloud, SNMP |
| Housing | Heavy-duty Steel Case |
| Certification | CE, RoHS, FCC |
| Warranty | 3 Years |
