RG-CS86-12XMG4VS-UP L3 Managed Switch, 12 x 10G Multi-G (UPoE), 4 x 25G
Stok 25
Highlight Features:• 12 x 10G Multi-Gigabit ports with PoE++ (90W) support.• 4 x 25G SFP28 high-speed uplink ports.• Ideal for Wi-Fi 7 and high-end workstation access.• Compact L3 switch with professional surge protection.
Ruijie RG-CS86-12XMG: Multi-Gigabit Access dengan Daya 90W
Maksimalkan performa Wi-Fi 6E/7 Anda dengan switch Multi-Gigabit ini. RG-CS86-12XMG4VS-UP menyediakan port 10Gbps tembaga (RJ45) lengkap dengan dukungan Ultra-PoE 90W untuk perangkat IoT paling canggih saat ini.
Keunggulan Produk:
- Kecepatan 10G Copper: Memberikan kecepatan 10Gbps melalui kabel LAN standar untuk efisiensi dan performa.
- 90W Power over Ethernet: Sanggup menghidupkan layar interaktif, lampu pintar, dan AP high-end tanpa kabel listrik tambahan.
- Uplink 25G SFP28: Siap untuk masa depan dengan jalur uplink yang jauh melampaui standar 10G tradisional.
| brands |
|---|
Technical Specifications
| Type | L3 Managed Multi-Gigabit PoE Switch |
| Fixed Ports | 12 x 100M/1G/2.5G/5G/10G Base-T (UPoE) |
| Uplink Ports | 4 x 25G SFP28 Slots (Compatible 10G) |
| PoE Standard | IEEE 802.3bt (90W per Port), af/at |
| PoE Budget | 600W (Expandable) |
| Switching Capacity | 440 Gbps |
| Forwarding Rate | 330 Mpps |
| MAC Address | 32K Entries |
| L3 Routing | OSPF, BGP, ISIS, Static, RIP |
| Stacking | VSU 2.0 Virtualization |
| Management | Ruijie Cloud, CLI, Web, SNMP v3 |
| Packet Buffer | 4 MB |
| VLAN IDs | 4094, Voice, Private, QinQ |
| Reliability | GR, BFD, DLDP, VRRP |
| Security | CPP, NFPP, DHCP Snooping, DAI |
| Power Supply | Dual Hot-swap Redundant AC |
| Power Consumption | < 750W (Full Load) |
| Dimensions | 442 x 420 x 44 mm (1U) |
| Weight | 7.2 kg |
| Operating Temp | 0°C to 50°C |
| Surge Protection | 10KV (Power & Ports) |
| IPv6 | Static, OSPFv3, BGP4+, MLD |
| QoS | 8 Queues, SP, WRR, DRR, WRED |
| Mirroring | SPAN, RSPAN, ERSPAN |
| Jumbo Frame | 9216 bytes |
| Fan Module | Hot-swappable N+1 Redundant |
| Certification | CE, FCC, RoHS |
| MTBF | > 200,000 hours |
| Housing | Full Metal Industrial Design |
| Warranty | 3 Years |
