RG-CS86-20XS4VS2QXS-D L3 Managed Switch, 20 x 10G, 4 x 25G, 2 x 40G Ports
Stok 25
Highlight Features:• 20 x 10G SFP+, 4 x 25G SFP28, and 2 x 40G QSFP+ ports.• High-performance Layer 3 distribution switch.• Supports VSU (Virtual Switching Unit) for simplified management.• Ideal for campus aggregation or small data center cores.
Ruijie RG-CS86-20XS-D: Switch Aggregation Full-Fiber untuk Kampus Masa Depan
Sempurnakan tulang punggung jaringan kampus Anda dengan RG-CS86-20XS4VS2QXS-D. Switch ini menawarkan kombinasi port fiber mulai dari 10G hingga 40G, memberikan jalur distribusi data yang sangat cepat antara switch akses dan pusat data.
Keunggulan Strategis:
- High-Speed Fiber Connectivity: Perpaduan port 10G, 25G, dan 40G memberikan fleksibilitas total untuk upgrade jaringan secara bertahap.
- Hardware Stacking (VSU): Gabungkan beberapa unit menjadi satu sistem virtual untuk manajemen yang jauh lebih mudah dan redundansi jalur.
- Keandalan Level Perusahaan: Dirancang untuk beban kerja nonstop dengan sistem operasi yang sangat stabil.
| brands |
|---|
Technical Specifications
| Type | L3 Managed Multi-Gigabit Aggregation Switch |
| Fixed Ports | 20 x 1/10G SFP+ Slots |
| Uplink Ports | 4 x 25G SFP28, 2 x 40G QSFP+ |
| Switching Capacity | 820 Gbps |
| Forwarding Rate | 600 Mpps |
| MAC Address | 64K Entries |
| L3 Routing | Static, RIP, OSPF, BGP, ISIS, MPLS, EVPN |
| Stacking | VSU 2.0 (Virtual Switch Unit) |
| Management | Ruijie Cloud, Web GUI, CLI, SNMP v3 |
| Power Supply | Dual Hot-swap Redundant AC/DC |
| Power Consumption | < 120W |
| Dimensions | 442 x 420 x 44 mm (1U) |
| Weight | 8.5 kg |
| Operating Temp | 0°C to 50°C |
| Cooling | N+1 Redundant Hot-swap Fans |
| Security | CPP, NFPP, IP Source Guard, DAI, ACL |
| VLAN | 4K VLAN IDs, QinQ, Private VLAN |
| ARP Table | Up to 32K Entries |
| IPv6 | Static, OSPFv3, BGP4+, MLD Snooping |
| VXLAN | Hardware VXLAN Gateway Support |
| Reliability | VRRP, REUP, BFD, GR for OSPF/BGP |
| Jumbo Frame | 9216 bytes |
| Latency | < 2μs |
| SDN Support | OpenFlow 1.3, NetConf, gRPC |
| Mirroring | SPAN, RSPAN, ERSPAN |
| Housing | Heavy-duty Galvanized Steel |
| Certification | CE, RoHS, FCC |
| MTBF | > 200,000 hours |
| Warranty | 3 Years |
