RG-CS86-24MG4VS-UP L3 Managed Switch, 24 x 2.5G Multi-Gigabit Ports (UPoE), 4 x 25G SFP28

Ruijie
Availability:

Stok 25


Highlight Features:• 24 x 2.5G Multi-Gigabit ports and 4 x 25G SFP28 uplinks.• Supports IEEE 802.3bt (90W PoE) for high-end Wi-Fi 6/7 APs.• Non-blocking Multi-Gigabit performance for modern workstations.• Cloud-managed with advanced Layer 3 routing capabilities.

Ruijie RG-CS86-24MG: Switch Multi-Gigabit dengan Ultra-High Power PoE

Produk ini adalah jawaban bagi perangkat yang membutuhkan daya dan data di atas rata-rata. Dengan port 2.5G Multi-Gigabit dan dukungan UPOE (hingga 90W), switch ini sanggup menghidupkan layar digital signage besar atau AP Wi-Fi 6 tercanggih hanya dengan satu kabel.

Fitur Unggulan:

  • Port 2.5Gbps Multi-Gigabit: Menghilangkan batasan kecepatan kabel standar untuk memaksimalkan performa Wi-Fi 6.
  • 90W Ultra PoE (UPOE): Mampu menyuplai daya ke perangkat berat yang tidak sanggup diangkat oleh switch PoE standar.
  • Perlindungan Jaringan Cerdas: Fitur keamanan port otomatis untuk mencegah gangguan dari perangkat luar yang tidak resmi.
SKU: RG-CS86-24MG4VS-UP Kategori: Brand:
brands

Technical Specifications

Type L3 Multi-Gigabit Access Switch (HPoE)
Fixed Ports 24 x 100M/1G/2.5G Base-T (PoE++)
Uplink Ports 4 x 25G SFP28 Slots
PoE Standard IEEE 802.3af/at/bt (PoE++ 90W)
PoE Budget 740W (Expandable to 1440W)
Switching Capacity 320 Gbps
Forwarding Rate 240 Mpps
MAC Address 32K Entries
L3 Protocols OSPF, BGP, ISIS, Static Routing
Virtualization VSU 2.0 Support
Management Web, CLI, Cloud, SNMP
Security CPP, NFPP, DHCP Snooping, Port Security
ARP Table Up to 16K
IPv6 Features Dual Stack IPv4/IPv6 Ready
Power Supply Dual Hot-swap Redundant Slots
Power Consumption < 1600W (Full PoE Load)
Dimensions 442 x 420 x 44 mm
Weight 9.2 kg
Cooling Intelligent N+1 Redundant Fans
Multicast IGMP v1/v2/v3, PIM-SM
QoS 8 Queues, SP, WRR, WRED
Jumbo Frame 9216 bytes
Surge Protection 10KV (High Reliability)
Reliability BFD, VRRP, REUP
Housing Metal Rackmount Chassis
Certification CE, FCC, RoHS
MTBF > 180,000 hours
Warranty 3 Years
