RG-CS86-24MG4VS-UP L3 Managed Switch, 24 x 2.5G Multi-Gigabit Ports (UPoE), 4 x 25G SFP28
Stok 25
Highlight Features:• 24 x 2.5G Multi-Gigabit ports and 4 x 25G SFP28 uplinks.• Supports IEEE 802.3bt (90W PoE) for high-end Wi-Fi 6/7 APs.• Non-blocking Multi-Gigabit performance for modern workstations.• Cloud-managed with advanced Layer 3 routing capabilities.
Ruijie RG-CS86-24MG: Switch Multi-Gigabit dengan Ultra-High Power PoE
Produk ini adalah jawaban bagi perangkat yang membutuhkan daya dan data di atas rata-rata. Dengan port 2.5G Multi-Gigabit dan dukungan UPOE (hingga 90W), switch ini sanggup menghidupkan layar digital signage besar atau AP Wi-Fi 6 tercanggih hanya dengan satu kabel.
Fitur Unggulan:
- Port 2.5Gbps Multi-Gigabit: Menghilangkan batasan kecepatan kabel standar untuk memaksimalkan performa Wi-Fi 6.
- 90W Ultra PoE (UPOE): Mampu menyuplai daya ke perangkat berat yang tidak sanggup diangkat oleh switch PoE standar.
- Perlindungan Jaringan Cerdas: Fitur keamanan port otomatis untuk mencegah gangguan dari perangkat luar yang tidak resmi.
| brands |
|---|
Technical Specifications
| Type | L3 Multi-Gigabit Access Switch (HPoE) |
| Fixed Ports | 24 x 100M/1G/2.5G Base-T (PoE++) |
| Uplink Ports | 4 x 25G SFP28 Slots |
| PoE Standard | IEEE 802.3af/at/bt (PoE++ 90W) |
| PoE Budget | 740W (Expandable to 1440W) |
| Switching Capacity | 320 Gbps |
| Forwarding Rate | 240 Mpps |
| MAC Address | 32K Entries |
| L3 Protocols | OSPF, BGP, ISIS, Static Routing |
| Virtualization | VSU 2.0 Support |
| Management | Web, CLI, Cloud, SNMP |
| Security | CPP, NFPP, DHCP Snooping, Port Security |
| ARP Table | Up to 16K |
| IPv6 Features | Dual Stack IPv4/IPv6 Ready |
| Power Supply | Dual Hot-swap Redundant Slots |
| Power Consumption | < 1600W (Full PoE Load) |
| Dimensions | 442 x 420 x 44 mm |
| Weight | 9.2 kg |
| Cooling | Intelligent N+1 Redundant Fans |
| Multicast | IGMP v1/v2/v3, PIM-SM |
| QoS | 8 Queues, SP, WRR, WRED |
| Jumbo Frame | 9216 bytes |
| Surge Protection | 10KV (High Reliability) |
| Reliability | BFD, VRRP, REUP |
| Housing | Metal Rackmount Chassis |
| Certification | CE, FCC, RoHS |
| MTBF | > 180,000 hours |
| Warranty | 3 Years |
