RG-CS88-08 Next-Generation High-Density Modular Campus Core Switch, 8 Slots
Stok 25
Highlight Features:• Next-generation chassis-based core switch with 8 slots.• High-performance architecture for large-scale campus cores.• Supports ultra-high-density 10G/40G/100G line cards.• Carrier-grade reliability with redundant control and power modules.
Ruijie RG-CS88-08: Core Switch Modular untuk Skalabilitas Tanpa Batas
Sebagai salah satu switch core paling inovatif, RG-CS88-08 menawarkan desain modular yang memungkinkan Anda menyesuaikan kapasitas jaringan sesuai pertumbuhan bisnis. Ini adalah investasi jangka panjang bagi perusahaan yang membutuhkan fleksibilitas tinggi di pusat data mereka.
Kelebihan Utama:
- Desain Modular yang Fleksibel: Pasang modul port sesuai kebutuhan, mulai dari Gigabit hingga 10G/40G, memberikan kustomisasi total pada jaringan Anda.
- Arsitektur High-Availability: Mendukung redundansi penuh pada modul kontrol dan power supply untuk menjamin uptime jaringan 100%.
- Performa Switching Masif: Menangani trafik data tingkat tinggi dengan latensi ultra-rendah, sangat cocok untuk lingkungan virtualisasi dan cloud.
- Virtualisasi VSU: Gabungkan beberapa unit menjadi satu sistem virtual untuk penyederhanaan manajemen dan peningkatan redundansi.
| brands |
|---|
Technical Specifications
| Type | Next-Gen Modular Campus Core Switch |
| Slots | 10 Slots (2 Management, 8 Service) |
| Switching Capacity | Up to 15.36 Tbps |
| Forwarding Rate | Up to 4608 Mpps |
| Architecture | Orthogonal Zero-Backplane |
| L3 Protocols | OSPF, BGP, ISIS, MPLS, EVPN, VPLS |
| Virtualization | VSU 2.0 (Up to 4 units), VSD |
| Redundancy | 1+1 Supervisor, N+M Power/Fan |
| MAC Address | Up to 256K Entries |
| ARP Table | Up to 128K Entries |
| ACL Entries | Up to 128K Entries |
| SDN Support | OpenFlow 1.3, NetConf |
| Power Supply | Hot-swap AC/DC Modules |
| Cooling | Vertical Airflow, Hot-swap Fans |
| Dimensions | 442 x 450 x 575 mm (13U) |
| Weight | ~40 kg (Empty Chassis) |
| IPv6 Ready | Phase 2 Gold Certified |
| Multicast | PIM-SM/DM/SSM, MSDP |
| QoS | H-QoS, 8 Queues, ECN |
| Interface Support | 1G/10G/25G/40G/100G Modules |
| Reliability | 99.999% Availability Design |
| Management Port | RJ45 Console, MGMT, USB |
| Airflow | Front-to-Rear Design |
| Operating Temp | 0°C to 45°C |
| Storage Temp | -40°C to 70°C |
| Surge Protection | 10KV for Power System |
| Status LEDs | System, Management, Fan, Power |
| Certification | CE, RoHS, FCC |
| MTBF | > 200,000 hours |
| Warranty | 3 Years |
Based on 0 reviews
Only logged in customers who have purchased this product may leave a review.
