RG-N18010-X Newton 18000-X Series Data Center Core Switch, 10 Slots
RG-N18010-X Newton 18000-X Series Data Center Core Switch, 10 Slots - Gambar 2
RG-N18010-X Newton 18000-X Series Data Center Core Switch, 10 Slots - Gambar 3
RG-N18010-X Newton 18000-X Series Data Center Core Switch, 10 Slots - Gambar 4
RG-N18010-X Newton 18000-X Series Data Center Core Switch, 10 Slots - Gambar 5
RG-N18010-X Newton 18000-X Series Data Center Core Switch, 10 Slots - Gambar 6

RG-N18010-X Newton 18000-X Series Data Center Core Switch, 10 Slots

Ruijie
Availability:

Stok 25

Highlight Features:• 10-slot next-gen modular core switch.• Supports high-density 100G/400G line cards.• Virtual Switching Unit (VSU) 3.0 for carrier-grade HA.• Advanced hardware-level OAM and telemetry.

Ruijie Newton RG-N18010-X: Performa Core Premium dengan Skalabilitas Cerdas

RG-N18010-X membawa kekuatan seri Newton X ke dalam ukuran yang lebih optimal. Dengan 10 slot ekspansi, switch ini memberikan keseimbangan antara performa komputasi tingkat tinggi dan efisiensi ruang rak di data center enterprise.

Kenapa Memilih Seri X?

  • Teknologi Fabric Terkini: Komunikasi antar modul yang sangat cepat untuk latensi yang nyaris nol.
  • Manajemen Berbasis AI: Mampu mendeteksi dan mengisolasi gangguan jaringan secara otomatis sebelum berdampak pada pengguna.
  • Dukungan SDN Penuh: Memudahkan otomatisasi jaringan skala besar melalui pengontrol perangkat lunak.
SKU: RG-N18010-X Kategori: Brand:
brands

Technical Specifications

Type Modular Core Chassis Switch
Slots 12 Slots (2 Management, 10 Service)
Switching Capacity Up to 230 Tbps
Forwarding Rate Up to 69,120 Mpps
Architecture Clos Non-blocking Architecture
L3 Features Static, OSPF, BGP, ISIS, MPLS, VPLS
Stacking VSU (Virtual Switch Unit) 2.0
VXLAN Gateway Hardware Layer 2/3 VXLAN Gateway
MAC Address Table Up to 512K / 1M
Reliability 1+1 Management, N+M Power/Fan
IPv6 Ready Full Dual-Stack IPv4/IPv6
Management CLI, SNMP, SSH, RMON, Cloud
Power Modules Hot-swappable AC/DC Modules
Fan Modules Hot-swappable Variable Speed Fans
Dimensions 442 x 820 x 753 mm (17U)
Weight ~75 kg (Empty)
Airflow Front-to-Rear Optimized
ARP Table Up to 256K
ACL Entries Up to 128K
SDN OpenFlow 1.3, NetConf
Multicast IGMP v1/v2/v3, PIM-SM/DM/SSM
QoS H-QoS, 8 Queues, SP, WRR
Buffer Intelligent Shared Distributed Buffer
Packet Mirroring SPAN, RSPAN, Flow-based Mirroring
Operating Humidity 10% to 90% RH
Certification CE, FCC, RoHS
Operating Temp 0°C to 45°C
MTBF > 250,000 hours
Warranty 3 Years
