Aggregation Routers
RG-RSR30-XA-24 Aggregation Router, High-Performance Multi-Service Router
Availability:
Stok 25
Highlight Features:• High-performance Aggregation Router for enterprise WAN.• Multi-service support including voice, security, and data.• Advanced routing protocols and QoS management.• Modular design with flexible interface expansion.
Ruijie RG-RSR30-XA-24: Router Agregasi Next-Gen untuk Konektivitas Cabang yang Aman
Hubungkan berbagai kantor cabang Anda ke pusat dengan keamanan dan performa maksimal. RG-RSR30-XA-24 adalah router agregasi kelas menengah yang dirancang untuk menangani beban trafik data, suara, dan video yang terenkripsi secara efisien dan aman.
Fitur Utama:
- Throughput Routing Tinggi: Menjamin akses data antar kantor berlangsung instan tanpa penundaan (latensi) yang berarti.
- Keamanan VPN Terintegrasi: Memberikan jalur komunikasi data rahasia antar cabang dengan enkripsi tingkat tinggi yang sulit ditembus.
- Manajemen Bandwidth Cerdas: Atur prioritas trafik aplikasi bisnis utama agar operasional perusahaan tetap lancar di bawah beban internet padat.
- Hardware Tangguh & Tahan Lama: Dirancang dengan standar ketahanan tinggi untuk operasional kritis yang membutuhkan uptime 99,99%.
| brands |
|---|
Technical Specifications
| Type | Ultra High-Density Aggregation Router |
| Expansion Slots | 24 SIC Slots / 12 HSEC Slots |
| Fixed Ports | 4 x 10/100/1000Base-T, 4 x 1G SFP |
| Forwarding Performance | Up to 12 Mpps |
| Switching Capacity | 240 Gbps |
| Memory | 4GB DDR3 RAM (Upgradeable) |
| Flash | 2GB NAND Flash |
| L3 Routing | BGP, OSPF, ISIS, MPLS, PBR, Static |
| VPN Capacity | Up to 3000 IPsec Tunnels |
| Encryption | Hardware AES, 3DES, SM2/SM3/SM4 |
| SD-WAN | Supported (Full Feature Set) |
| QoS | H-QoS, PQ, CQ, WFQ, CBWFQ, GTS |
| Reliability | Dual Redundant Hot-swap Power Supply |
| Interface Modules | E1/T1, Serial, FXS, FXO, 4G LTE, 10G SFP+ |
| IPv6 | Full Dual Stack, IPv6 Routing, Tunneling |
| Management | CLI, Web, SNMP v1/v2/v3, Ruijie Cloud |
| Multicast | PIM-SM, PIM-DM, IGMP, MSDP |
| Dimensions | 440 x 420 x 266 mm (6U) |
| Weight | ~25 kg (Full Load) |
| Operating Temp | 0°C to 45°C |
| Cooling | Force Air Cooling (N+1 Fans) |
| Surge Protection | 8KV (Common Mode) |
| Housing | Industrial Modular Chassis |
| BGP Tables | Up to 1M Entries |
| NAT | High-performance NAT/CGNAT Support |
| Certification | CE, RoHS, FCC |
| MTBF | > 150,000 hours |
| Warranty | 3 Years |
