RG-RSR77-XA-08 Modular Core Router, 8-Slot Carrier-Grade Backbone
Stok 25
Highlight Features:• Flagship Modular Core Router with 8 service slots.• Massive switching capacity for ISP and large campus cores.• Comprehensive IPv4/IPv6 dual-stack support.• Modular and hot-swappable components for zero downtime.
Ruijie RG-RSR77-XA-08: Pusat Komando Jaringan dengan Skalabilitas Ekstrim
Didesain untuk menjadi tulang punggung (backbone) jaringan yang paling kompleks, RG-RSR77-XA-08 menawarkan 8 slot modular untuk kapasitas ekspansi yang masif. Ini adalah solusi bagi penyedia layanan (ISP) atau organisasi global yang membutuhkan kontrol trafik data dalam volume yang sangat besar.
Manfaat bagi Organisasi:
- Skalabilitas Luar Biasa: Kapasitas ekspansi port yang sangat luas untuk mengakomodasi pertumbuhan jaringan hingga beberapa tahun ke depan.
- Prosesor Performa Tinggi: Mampu melakukan inspeksi paket data mendalam dan manajemen enkripsi berat secara instan.
- Manajemen Energi Cerdas: Meskipun bertenaga monster, sistem pendinginan cerdasnya menjaga efisiensi penggunaan daya tetap optimal.
| brands |
|---|
Technical Specifications
| Type | Modular Next-Gen Core Router |
| Total Slots | 10 Slots (2 Management, 8 Service) |
| Switching Capacity | Up to 10.24 Tbps |
| Forwarding Rate | Up to 2400 Mpps |
| Architecture | Distributed Orthogonal Architecture |
| L3 Protocols | BGP, OSPF, ISIS, MPLS, VPLS, EVPN |
| VPN Support | High-capacity IPsec, MPLS L2/L3 VPN |
| SDN Support | OpenFlow 1.3, NetConf, gRPC |
| Virtualization | VSU (Virtual Switch Unit) Support |
| Redundancy | 1+1 Supervisor, N+M Power, N+1 Fan |
| Management | Web, CLI, SNMP v1/v2/v3, Cloud |
| Service Modules | 1G/10G/25G/40G/100G Ethernet Modules |
| IPv6 Ready | Phase 2 Gold Certified |
| Multicast | PIM-SM/DM/SSM, MSDP, MBGP |
| QoS | H-QoS (5-level), Traffic Shaping |
| Power Supply | Redundant Hot-swap AC/DC Modules |
| Power Consumption | < 2500W (Full Configuration) |
| Dimensions | 442 x 450 x 575 mm (13U) |
| Weight | ~45 kg (Empty Chassis) |
| Operating Temp | 0°C to 45°C |
| Airflow | Front-to-Rear Cooling Path |
| Security | CPP, NFPP, Anti-DDoS Architecture |
| VLAN | 4K VLAN IDs, QinQ |
| ARP Table | Up to 512K Entries |
| MAC Address | Up to 512K Entries |
| Reliability | 99.999% High Availability Design |
| Certification | CE, RoHS, FCC |
| MTBF | > 200,000 hours |
| Warranty | 3 Years |
