RG-S5310-24SFP4XS-E L3 Managed Switch, 24 x SFP, 4 x 10G SFP+

Ruijie
Availability:

Stok 25


Highlight Features:• 24 x SFP fiber ports and 4 x 10G SFP+ uplinks.• Ideal for high-density fiber-to-the-desk access.• Full Layer 3 routing and IPv6 support.• VSU stacking and advanced hardware security.

Ruijie RG-S5310-24SFP4XS-E: Agregasi Fiber Gigabit untuk Jaringan Terdistribusi

RG-S5310-24SFP4XS-E adalah switch agregasi full-fiber yang dirancang untuk menghubungkan berbagai switch akses di gedung atau area yang berjauhan. Dengan 24 port SFP dan 4 uplink 10G SFP+, switch ini memberikan transmisi data berbasis cahaya yang stabil dan bebas gangguan interferensi listrik.

Keunggulan Strategis:

  • Konektivitas Fiber Optik Murni: Memberikan fleksibilitas jangkauan ribuan meter untuk menghubungkan titik-titik jaringan yang tersebar.
  • Uplink 10Gbps SFP+: Menjamin jalur utama menuju core switch tetap bertenaga tanpa risiko bottleneck.
  • Fitur Layer 3 Lite: Mendukung fungsi routing statis untuk manajemen lalu lintas antar-VLAN yang lebih efisien.
  • Ketahanan Tinggi: Komponen berkualitas enterprise yang siap bekerja nonstop 24/7.
SKU: RG-S5310-24SFP4XS-E Kategori: Brand:
brands

Technical Specifications

Type L3 Managed Gigabit Fiber Aggregation Switch
Fixed Ports 24 x 100/1000Base-X SFP Slots
Uplink Ports 4 x 10G SFP+ Slots
Switching Capacity 128 Gbps
Forwarding Rate 96 Mpps
MAC Address 16K Entries
L3 Routing Static Routing, RIP, OSPF, BGP
Stacking VSU 2.0 (Virtual Switch Unit)
Management Web, CLI (Console), SNMP v1/v2/v3, RMON
VLAN Support 4K VLAN IDs, GVRP, QinQ, Voice VLAN
Security CPP, NFPP, IP Source Guard, DAI
ACL Standard, Extended, L2-L4 ACL
IPv6 Static, OSPFv3, BGP4+, MLD Snooping
Reliability VRRP, REUP, BFD, GR for OSPF/BGP
Power Supply Built-in AC 100-240V
Power Consumption < 45W
Dimensions 440 x 260 x 44 mm (1U)
Weight 3.8 kg
Operating Temp 0°C to 50°C
Storage Temp -40°C to 70°C
Surge Protection 10KV (High Reliability)
Cooling Smart Cooling Fans
ARP Table 8K Entries
Jumbo Frame 9216 bytes
Multicast IGMP v1/v2/v3, PIM-SM
Mirroring Many-to-One, RSPAN
QoS 8 Queues, SP, WRR, DRR
Certification CE, RoHS, FCC
MTBF > 200,000 hours
Warranty 3 Years
