RG-S5310-24SFP4XS-E L3 Managed Switch, 24 x SFP, 4 x 10G SFP+
Stok 25
Highlight Features:• 24 x SFP fiber ports and 4 x 10G SFP+ uplinks.• Ideal for high-density fiber-to-the-desk access.• Full Layer 3 routing and IPv6 support.• VSU stacking and advanced hardware security.
Ruijie RG-S5310-24SFP4XS-E: Agregasi Fiber Gigabit untuk Jaringan Terdistribusi
RG-S5310-24SFP4XS-E adalah switch agregasi full-fiber yang dirancang untuk menghubungkan berbagai switch akses di gedung atau area yang berjauhan. Dengan 24 port SFP dan 4 uplink 10G SFP+, switch ini memberikan transmisi data berbasis cahaya yang stabil dan bebas gangguan interferensi listrik.
Keunggulan Strategis:
- Konektivitas Fiber Optik Murni: Memberikan fleksibilitas jangkauan ribuan meter untuk menghubungkan titik-titik jaringan yang tersebar.
- Uplink 10Gbps SFP+: Menjamin jalur utama menuju core switch tetap bertenaga tanpa risiko bottleneck.
- Fitur Layer 3 Lite: Mendukung fungsi routing statis untuk manajemen lalu lintas antar-VLAN yang lebih efisien.
- Ketahanan Tinggi: Komponen berkualitas enterprise yang siap bekerja nonstop 24/7.
| brands |
|---|
Technical Specifications
| Type | L3 Managed Gigabit Fiber Aggregation Switch |
| Fixed Ports | 24 x 100/1000Base-X SFP Slots |
| Uplink Ports | 4 x 10G SFP+ Slots |
| Switching Capacity | 128 Gbps |
| Forwarding Rate | 96 Mpps |
| MAC Address | 16K Entries |
| L3 Routing | Static Routing, RIP, OSPF, BGP |
| Stacking | VSU 2.0 (Virtual Switch Unit) |
| Management | Web, CLI (Console), SNMP v1/v2/v3, RMON |
| VLAN Support | 4K VLAN IDs, GVRP, QinQ, Voice VLAN |
| Security | CPP, NFPP, IP Source Guard, DAI |
| ACL | Standard, Extended, L2-L4 ACL |
| IPv6 | Static, OSPFv3, BGP4+, MLD Snooping |
| Reliability | VRRP, REUP, BFD, GR for OSPF/BGP |
| Power Supply | Built-in AC 100-240V |
| Power Consumption | < 45W |
| Dimensions | 440 x 260 x 44 mm (1U) |
| Weight | 3.8 kg |
| Operating Temp | 0°C to 50°C |
| Storage Temp | -40°C to 70°C |
| Surge Protection | 10KV (High Reliability) |
| Cooling | Smart Cooling Fans |
| ARP Table | 8K Entries |
| Jumbo Frame | 9216 bytes |
| Multicast | IGMP v1/v2/v3, PIM-SM |
| Mirroring | Many-to-One, RSPAN |
| QoS | 8 Queues, SP, WRR, DRR |
| Certification | CE, RoHS, FCC |
| MTBF | > 200,000 hours |
| Warranty | 3 Years |
