RG-S5310-48SFP4XS-E L3 Managed Switch, 48 x SFP, 4 x 10G SFP+
Stok 25
Highlight Features:• 48 x SFP fiber ports and 4 x 10G SFP+ uplinks.• High-density fiber aggregation for campus networks.• Supports hot-swappable dual power supplies.• Comprehensive L2/L3 management features.
Ruijie RG-S5310-48SFP4XS-E: Konsolidasi Fiber Densitas Tinggi
Mencari solusi untuk mengumpulkan puluhan jalur fiber dalam satu unit? Switch ini menawarkan 48 port SFP, menjadikannya pilihan utama sebagai titik konsolidasi bagi jaringan kampus atau kawasan industri yang menggunakan infrastruktur serat optik secara masif.
Manfaat bagi Bisnis:
- Densitas Port Maksimal: Mengelola 48 koneksi fiber Gigabit dalam satu unit rackmount yang ringkas.
- Skalabilitas Luar Biasa: Sangat ideal untuk ekspansi jaringan yang membutuhkan banyak titik koneksi jarak jauh.
- Manajemen Cloud Terpadu: Monitoring kesehatan link fiber secara real-time melalui dashboard Ruijie Cloud yang intuitif.
| brands |
|---|
Technical Specifications
| Type | L3 Managed High-Density Fiber Switch |
| Fixed Ports | 48 x 100/1000Base-X SFP Slots |
| Uplink Ports | 4 x 10G SFP+ Slots |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 132 Mpps |
| MAC Address | 16K Entries |
| L3 Routing | Full L3 Stack (OSPF, BGP, RIP, PBR) |
| Virtualization | VSU (Up to 9 units) |
| Management | Ruijie Cloud, Web, CLI, SNMP |
| Reliability | GR, BFD, DLDP, VRRP |
| VLAN | 4094 VLANs, Private VLAN, Super VLAN |
| Security | CPP, NFPP, DHCP Snooping, Port Security |
| ARP Table | Up to 8K |
| IPv6 Features | Dual Stack, OSPFv3, BGP4+, MLD |
| Power Supply | Built-in AC 100-240V |
| Power Consumption | < 75W |
| Dimensions | 440 x 300 x 44 mm (1U) |
| Weight | 5.2 kg |
| Cooling | Triple Smart Speed Fans |
| Operating Temp | 0°C to 50°C |
| Humidity | 10% to 90% RH |
| Surge Protection | 10KV |
| Jumbo Frame | 9216 bytes |
| Multicast | IGMP Snooping, MLD Snooping, PIM |
| QoS | Strict Priority, WRR, WRED |
| Mirroring | SPAN, RSPAN, ERSPAN |
| Housing | Galvanized Steel |
| Certification | CE, FCC, RoHS |
| MTBF | > 180,000 hours |
| Warranty | 3 Years |
