RG-S5760C-48SFP4XS-X L3 Managed Switch, 48 x 100/1000M SFP Ports, 4 x 1G/10G SFP+ Ports
Stok 25
Highlight Features:• 48 x SFP ports and 4 x 10G SFP+ uplink ports.• Ideal for high-density fiber-to-the-desk deployments.• Full Layer 3 routing and IPv6 support.• Intelligent fan speed adjustment for low noise.
Ruijie RG-S5760C-48SFP4XS-X: Agregasi Fiber Densitas Tinggi untuk Backbone Perusahaan
Dirancang untuk menjadi tulang punggung (Backbone) jaringan yang sangat luas, switch ini menawarkan 48 port SFP untuk koneksi fiber optik yang masif. RG-S5760C-48SFP4XS-X adalah investasi jangka panjang untuk perusahaan yang mengutamakan kecepatan cahaya di seluruh lini operasional mereka.
Keunggulan Utama:
- Kapasitas Agregasi Masif: Mampu mengonsolidasikan hingga 48 titik akses fiber optik dalam satu perangkat, mengurangi jumlah perangkat yang perlu dikelola di pusat data.
- Mendukung VXLAN: Memungkinkan segmentasi jaringan tingkat lanjut secara virtual, memisahkan trafik departemen yang sensitif dengan keamanan maksimal.
- Performa Switching Line-Rate: Tidak ada penundaan data pada semua port, memberikan jaminan throughput maksimal untuk aplikasi video streaming dan VoIP.
- Proteksi Petir Industrial: Dilengkapi dengan perlindungan lonjakan arus hingga 10KV, memberikan rasa aman ekstra saat cuaca buruk.
| brands |
|---|
Technical Specifications
| Brand | Ruijie Networks |
| Fixed Ports | 48 x 1G SFP, 4 x 10G SFP+ Uplink |
| Type | Layer 3 Fiber-Access Switch |
| Switching Capacity | 176 Gbps / 1.76 Tbps |
| Forwarding Rate | 132 Mpps |
| MAC Address | 32,000 |
| VLAN IDs | 4,094 |
| ARP Table | 8,000 |
| Routing Table | 12,000 (IPv4), 6,000 (IPv6) |
| L3 Protocols | Static, RIP, OSPF, BGP, PBR, ECMP |
| Virtualization | VSU 2.0 (Virtual Switch Unit) |
| L2 Protocols | IEEE 802.1q, STP, RSTP, MSTP, ERPS, LACP |
| Multicast | IGMP Snooping v1/v2/v3, MLD Snooping |
| ACL | Standard, Extended, Time-range, IPv6 ACL |
| QoS Queues | 8 Queues per port |
| Traffic Scheduling | SP, WRR, DRR, SP+WRR |
| Security | CPP, NFPP, DHCP Snooping, Port Security |
| Management | CLI, Telnet, SSH, SNMP, Web, Ruijie Cloud |
| Surge Protection | 10 KV |
| CPU / RAM | Multi-core / 512 MB |
| Flash Memory | 512 MB |
| Console Port | 1 x RJ45 Port |
| MTBF | > 200,000 hours |
| Power Consumption | < 65W |
| Power Input | 100V – 240V AC |
| Operating Temp | -5°C to 50°C |
| Storage Temp | -40°C to 70°C |
| Operating Humidity | 10% to 90% RH |
| Dimensions | 442 x 300 x 44 mm |
| Weight | ± 4.2 kg |
| Certification | CE, FCC, RoHS |
