RG-S6580-48CQ8QC Data Center 100G High-Density Fixed Access Switch with 400GE Uplink(Backward Compatibility with 100GE)
RG-S6580-48CQ8QC Data Center 100G High-Density Fixed Access Switch with 400GE Uplink(Backward Compatibility with 100GE) - Gambar 2
RG-S6580-48CQ8QC Data Center 100G High-Density Fixed Access Switch with 400GE Uplink(Backward Compatibility with 100GE) - Gambar 3
RG-S6580-48CQ8QC Data Center 100G High-Density Fixed Access Switch with 400GE Uplink(Backward Compatibility with 100GE) - Gambar 4
RG-S6580-48CQ8QC Data Center 100G High-Density Fixed Access Switch with 400GE Uplink(Backward Compatibility with 100GE) - Gambar 5
RG-S6580-48CQ8QC Data Center 100G High-Density Fixed Access Switch with 400GE Uplink(Backward Compatibility with 100GE) - Gambar 6

RG-S6580-48CQ8QC Data Center 100G High-Density Fixed Access Switch with 400GE Uplink(Backward Compatibility with 100GE)

Ruijie
Availability:

Stok 25

Highlight Features:• 48 x 100G QSFP28 and 8 x 400G QSFP-DD high-density ports.• Advanced RDMA over Converged Ethernet (RoCE) support.• Telemetry and gRPC support for network automation.• Redundant hot-swappable power and fan modules.

Ruijie RG-S6580-48CQ8QC: Revolusi Konektivitas 100G untuk Performa Tanpa Kompromi

Era 10G dan 40G mulai bergeser menuju 100G, dan RG-S6580-48CQ8QC adalah garda terdepan dalam transisi ini. Switch ini dirancang untuk lingkungan yang membutuhkan bandwidth luar biasa besar seperti Data Center, HPC (High Performance Computing), dan tulang punggung (Backbone) jaringan kampus. Dengan desain densitas tinggi, perangkat ini memungkinkan konsolidasi server yang lebih efisien dalam satu rak.

Keunggulan Kompetitif:

  • Terobosan Bandwidth 100Gbps: Mendukung transmisi data ultra-cepat yang meminimalisir latensi, sangat ideal untuk beban kerja AI, rendering grafis berat, dan database skala besar.
  • Telemetri Jaringan Real-Time: Memberikan visibilitas total terhadap kondisi jaringan. Admin IT dapat memprediksi potensi kemacetan (bottleneck) sebelum terjadi gangguan pada layanan pengguna.
  • Ketahanan Kelas Enterprise: Memanfaatkan sistem operasi modular yang stabil, memastikan uptime maksimal untuk layanan misi kritis yang tidak boleh terputus sedetik pun.
  • Fleksibilitas Port: Kombinasi port 40G dan 100G memberikan kebebasan bagi tim IT untuk merancang topologi jaringan yang paling optimal bagi perusahaan.
SKU: RG-S6580-48CQ8QC Kategori: Brand:
brands

Technical Specifications

Type 25G/100G Data Center Switch
Fixed Ports 48 x 25G SFP28, 8 x 100G QSFP28
Management Ports 1 Console, 1 Management, 1 USB 2.0
Switching Capacity 4.0 Tbps
Forwarding Rate 2,000 Mpps
Packet Buffer 22 MB
MAC Address 160,000
ARP Table 48,000
Routing Table 64,000 (IPv4), 32,000 (IPv6)
VXLAN Hardware-based VTEP, VXLAN Routing
L3 Features OSPF, BGP, ISIS, PBR, ECMP (64-way)
RDMA RoCE v2 Support
Telemetry In-band Network Telemetry (INT), gRPC
SDN Support OpenFlow 1.3, Netconf
VSU Stacking Supported (Up to 9 units)
QoS SP, WRR, WRED, PFC, ETS
VLAN 4,094 IDs, Voice VLAN, QinQ
Security CPP, NFPP, ACL, Port Security
Power Redundancy 1+1 Hot-swap AC/DC PSU
Fan Redundancy 3+1 Hot-swap Fans
Airflow Front-to-Rear or Rear-to-Front
Max Power < 450W
CPU Multi-core Processor
RAM 4 GB
Flash 8 GB
MTBF > 250,000 hours
Dimensions 442 x 560 x 44 mm (1U)
Weight 10.5 kg
Operating Temp 0°C to 45°C
Certification CE, FCC, RoHS, VCCI
