RG-S7620-20SFX2CQ Modular Campus Core Switch, Carrier-Grade 20-Slot
Stok 25
Highlight Features:• Enterprise-class aggregation switch with 20 x 10G and 100G uplinks.• Hardware-level high availability with VSU (Virtual Switching Unit) 3.0.• Comprehensive security features including ACL, CPP, and anti-DDoS.• Ruijie Cloud-ready for simplified remote monitoring and O&M.
Ruijie RG-S7620-20SFX2CQ: Pusat Distribusi 10G untuk Performa Maksimal
Tingkatkan performa jaringan agregasi Anda dengan dukungan port 10G SFP+ yang melimpah. RG-S7620-20SFX2CQ dirancang untuk menjadi titik konsolidasi bagi switch-switch akses berkecepatan tinggi, memastikan seluruh data dari tiap lantai terkirim ke core switch dengan kecepatan cahaya.
Kelebihan Strategis:
- Densitas 10G SFP+: 20 port 10Gbps memberikan kapasitas agregasi yang luar biasa untuk infrastruktur modern.
- Dual 100G Backbone: Mendukung redundansi jalur utama menuju core network untuk menjamin nol downtime.
- Teknologi Virtualisasi VSU: Sederhanakan manajemen dengan menggabungkan beberapa unit switch menjadi satu sistem virtual yang kuat.
- Keamanan Port Canggih: Melindungi integritas data perusahaan dari akses ilegal di tingkat agregasi.
| brands |
|---|
Technical Specifications
| Type | High-Density Core/Aggregation Switch |
| Fixed Ports | 20 x 10G SFP+, 2 x 100G QSFP28 |
| Expansion Slot | Available for 10G/40G/100G Modules |
| Switching Capacity | 2.56 Tbps |
| Forwarding Rate | 1920 Mpps |
| Architecture | Non-blocking Line-rate |
| L3 Features | OSPF, BGP, PBR, MPLS L3VPN |
| Virtualization | VSU (Up to 9 units) |
| MAC Address Table | 96K Entries |
| ARP Table | 40K Entries |
| VLAN | Voice VLAN, Super VLAN, Private VLAN |
| Reliability | VRRP, REUP, GR for OSPF/BGP |
| Power Redundancy | 1+1 Hot-swap AC/DC |
| Power Consumption | < 350W |
| Dimensions | 442 x 400 x 44 mm (1U) |
| Weight | 10.5 kg |
| Fan Module | Hot-swappable N+1 Redundancy |
| Management | SNMP, CLI, Web, Ruijie Cloud |
| Security | IP/MAC/Port Binding, Anti-DDoS |
| ACL | L2-L4 ACL, IPv6 ACL |
| Mirroring | Many-to-One, RSPAN |
| Multicast | IGMP Snooping, PIM-DM |
| QoS | Strict Priority, WRED |
| Jumbo Frame | 9,216 bytes |
| Operating Humidity | 10% to 90% RH |
| Storage Temp | -40°C to 70°C |
| IPv6 Ready | Phase 2 Gold Certified |
| Certification | CE, FCC |
| MTBF | > 180,000 hours |
| Warranty | 3 Years |
