RG-S7810C Next-Gen Core Switch for Campus Networks, 10 Slots

Ruijie
Availability:

Stok 25

Highlight Features:• Chassis-based core switch with 10 slots for extreme density.• High switching capacity for large campus cores.• Supports hot-swappable line cards and power modules.• Carrier-grade reliability and VSU 3.0 support.

Ruijie RG-S7810C: Chassis Core Switch Generasi Baru untuk Jaringan Kampus

Sebagai pusat dari jaringan Anda, RG-S7810C menawarkan arsitektur chassis modular dengan 10 slot ekspansi. Ini adalah solusi untuk core network skala raksasa yang membutuhkan fleksibilitas, redundansi total, dan performa switching hingga hitungan Terabit per detik.

Fitur Unggulan:

  • Desain Modular 10 Slot: Pasang modul port Gigabit, 10G, atau 40G/100G sesuai kebutuhan perkembangan bisnis Anda.
  • Redundansi Penuh: Modul kontrol dan power supply yang dapat diganti tanpa mematikan sistem (Hot-swappable).
  • Kapasitas Switching Masif: Dirancang untuk menjadi tulang punggung bagi ribuan pengguna dan trafik data cloud yang intens.
SKU: RG-S7810C Kategori: Brand:
brands

Technical Specifications

Type Modular Core Chassis Switch
Chassis Slots 12 Slots (2 Management, 10 Service)
Switching Capacity Up to 19.2 Tbps
Forwarding Rate Up to 5760 Mpps
Architecture Clos Non-blocking Multi-stage
Redundancy N+1 Power, N+M Management, Fans
L3 Routing Full L3 (OSPF, BGP, MPLS, VPLS)
Virtualization VSU 2.0 / VSD (Virtual Switch Device)
MAC Address Up to 512K (Depending on Module)
IPv6 Features Full Dual Stack, IPv6 Tunneling
Management Console, MGMT, SNMP, SSH, Cloud
Reliability 99.999% Availability
Power Supply Hot-swappable AC/DC Modules
Cooling Hot-swappable Fan Trays
Dimensions 442 x 450 x 664 mm (15U)
Weight ~45 kg (Empty) / ~110 kg (Full)
ARP Table Up to 128K
ACL Entries Up to 128K
SDN Support OpenFlow 1.3, NetConf
Security CPP, NFPP, Anti-DDoS
Multicast PIM-DM, PIM-SM, PIM-SSM
QoS H-QoS, WRR, DRR, SP
Jumbo Frame 9KB
Operating Temp 0°C to 45°C
Operating Humidity 10% to 90%
Interface Support 1G / 10G / 40G / 100G
Certification CE, RoHS, FCC
Hardware Monitoring Real-time Power & Temp
Stacking VSU Virtualization Up to 4 Units
Warranty 3 Years
