Ruijie Ceiling AP RG-RAP2266
Stok 30
AX3000 Dual band (2.4GHz&5GHz) access points, 2×2 MU-MIMO
2.4 GHz: 3.5dBi @574Mbps, 5 GHz: 5dBi @2402Mbps, Max. 8 SSID, 160MHz
1× Gigabit LAN Ports (PoE-In), 803at/802.3af PoE, DC 12V/2A, power consumption < 18 Watts
TX power: 2.4GHz @27dBm, 5GHz @23dBm
Max. STAs: 512, recommended STAs: 110 STAs
Support Beamforming, Layer2/3/AI/802.11k/v/r roaming, SNMP, Router mode, Standalone Captive portal, Mesh, Master AP in Self-organizing Network , Cloud/Eweb/APP management
Rp2.097.000
Stok 30
AX3000 Dual band (2.4GHz&5GHz) access points, 2×2 MU-MIMO
2.4 GHz: 3.5dBi @574Mbps, 5 GHz: 5dBi @2402Mbps, Max. 8 SSID, 160MHz
1× Gigabit LAN Ports (PoE-In), 803at/802.3af PoE, DC 12V/2A, power consumption < 18 Watts
TX power: 2.4GHz @27dBm, 5GHz @23dBm
Max. STAs: 512, recommended STAs: 110 STAs
Support Beamforming, Layer2/3/AI/802.11k/v/r roaming, SNMP, Router mode, Standalone Captive portal, Mesh, Master AP in Self-organizing Network , Cloud/Eweb/APP management
| brands |
|---|
Product Overview
AX3000 Wi-Fi 6 High-Performance Indoor Ceiling Access Point. Features an ultra-slim industrial design with 160MHz channel width for maximum efficiency.
Technical Specifications
| Brand | Ruijie Reyee |
| Product Model | RG-RAP2266 |
| Product Type | Indoor Ceiling Access Point |
| Wi-Fi Standard | Wi-Fi 6 (802.11ax), 802.11ac Wave2, 802.11n |
| Frequency Band | Dual-Band (2.4 GHz + 5 GHz) |
| Spatial Streams | 2 Streams |
| 2.4 GHz Speed | Up to 574 Mbps |
| 5 GHz Speed | Up to 2402 Mbps |
| Maximum Data Rate | 2976 Mbps |
| Wireless Technology | MU-MIMO, OFDMA, 1024-QAM, 160MHz |
| Ethernet Port | 1 x 10/100/1000Base-T (PoE In) |
| Power Supply | 802.3at PoE+ or DC 12V/1.5A |
| Maximum Power Consumption | ≤ 18 W |
| Maximum Clients | Up to 512 Clients |
| Dimensions | 180 x 180 x 30 mm |
| Weight | ≤ 0.5 kg |
| Mounting | Ceiling / Wall Mount |
| Operating Temperature | 0°C – 40°C |
| Protection Rating | IP41 |
| Management | Ruijie Reyee Cloud Management |
